PP Biaxial Geogrid Polypropylene Plastic Geogrid for soil stabilier road reinforcement
Biaxial geogrid is made of high molecular polymer through extrusion, forming and punching before longitudinal and lateral stretching. Biaxial geogrid This material has considerable tensile strength in longitudinal and lateral directions. Biaxial geogrid This chain structure can effectively bear and diffuse forces on soil and is applicable to large area permanent load bearing foundation as a reinforcement material.
Biaxial geogrid Applications:
Biaxial geogrid Make reinforce treatment for various kinds of soft soil foundation to evenly distribute load stress andreduce uneven settlement, not easy to generate static electricity, and flammability property good in the coal mine. Biaxial geogrid,It is easy to wash coal.Used in highway, railway, port, airport and municipal project. Support in the recovery working face of coal mine and roadway in the coal mine.
PP Biaxial Geogrid Specification
| Biaxial geogrid Index Properties | Unint | 15-15KN | 20-20KN | 30-30KN | 40-40kn | 50-50KN | |||||
| Biaxial geogrid Tensile Strength | KN/m | MD | TD | MD | TD | MD | TD | MD | TD | MD | TD |
| Biaxial geogrid Minimum Carbon Black | % | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 |
| Biaxial geogrid Tensile Strength@ 2% Strain | KN/m | 5 | 5 | 7 | 7 | 10.5 | 10.5 | 14 | 14 | 17.5 | 17.5 |
| Biaxial geogrid Tensile Strength@ 5% Strain | KN/m | 7 | 7 | 14 | 14 | 21 | 21 | 28 | 28 | 35 | 35 |
| Biaxial geogrid Roll width | 1-6m | ||||||||||
| Biaxial geogrid Roll lenth | 50m or 100m | ||||||||||
| Note: MD = Machine Direction; TD = Transverse Direction. | |||||||||||
Biaxial Geogrid Application:
Biaixal Geogrids focus almost entirely on reinforcement applications, although separation may be a function. The following are examples of a few applications.
Slope Reinforcement- embankments over soft soils, extra-steep earthwork slopes, landfill liner systems, and industrial and contaminated land reclamation
Base Reinforcement- foundations of roadbeds, parking lots, railroad tracks beds, airports runways, permanent unpaved roads, construction haul roads
Wall Reinforcement- retaining walls, sea walls, airport noise barriers, and bridge supports
Berm Reinforcement - spillway channels for earthen dams, levees, and waste contaminated ponds, banks for earthen canals and waterways.
FAQ
1, What is the difference between uniaxial and biaxial geogrid?
Biaxial geogrids are those that exhibit the same strength in both the machine directions MD and cross-machine directions CMD while uniaxial geogrids exhibit the primary strength in the machine direction with minimal strength, enough to maintain the aperture structure, in the cross-machine direction.
2, How many types of geogrids are there?
There are three different types of geogrids: Uniaxial, Biaxial, and Triaxial . Each one is designed and manufactured for specific construction applications with various tensile strengths.
3: How long is the delivery time?
Generally it is 2-3 days if the goods are in stock. Or 10-15 days if not in stock, according to the quantity.
4:Do you provide Biaxial geogrid samples?
Yes
