Product Introduction
Our high density polyethylene (HDPE) geomembranes provide an impermeable barrier against a wide range of solids and liquids. They exhibit excellent chemical and UV resistance,impermeability, and high yield and welded seam strengths, which is widely used as the liner.
Geomembrane data
| Geomembrane | |||||||||
| item | Specification | ||||||||
| Type | M0.3 | M0.4 | M0.5 | M0.6 | M1.0 | M1.5 | M2.0 | M2.5 | M3.0 |
| Vertical Breaking strength(KN/M≥) | 3 | 5 | 6 | 8 | 12 | 17 | 18 | 19 | 20 |
| Vertical and horizontal tensile elongation at break(% ≥) | 100 | 300 | 500 | ||||||
| Vertical and horizontal right angle tearing strength(N/mm≥) | 10 | 15 | 20 | 30 | 40 | 80 | 100 | 120 | 150 |
| CBR Bursting strength(KN≥) | 1 | 1.5 | 2.5 | 3 | 4 | 5 | 6 | 7 | 8 |
1) Good physical and mechanic performance
2) High tearing resistance, strong deformation adaptability
3) Puncture-resisting, aging resisting, ultra-violet radiation, oil and salt, and corrosion resistance
4) Good adaptability to high and low temperature, non-toxicity, long service life
5) Good waterproof, drainage, anti-seepage and damp proof effects
6) Complete width and thickness specifications, low cost and easy installation.
Product Application Range
1) Domestic and Hazardous Waste landfills
2) Landfill closures
3) Heap leach and tailing dams
4) Biogas Management
5) Floating Covers
6) Waste water treatment reservoirs
